High Voltage Battery Power Gauge
The remaining power of the high voltage battery is indicated when the power switch is switched ON.
When the high voltage battery is fully charged, F is indicated. As the level lowers, the needle approaches E. When the high voltage battery charge decreases to 1/4 or lower, we recommend charging the battery.
-
F (Fully charged)
-
1/4 charged
-
E (Fully discharged)
When the remaining charge of the high voltage battery is low, output may be restricted. If the output is restricted, charge the battery as soon as possible.
-
After charging, it may require some time for the needle to stabilize.
-
The
arrow indicates that the charging port is on the right side.
